Flexible Soft LED COB Strip Light High CRI>90 DC12V/DC24V FPC 8MM 10W/M 50W/Roll 3000K 4000K 6000K With 3 Year Warranty
Product Description
COB FOB STRIP: High Density, High CRI, High Brightness, Uniform Light Emission, No Graininess, No Light Spot, No Shadow, Customized Light Color according to Customers' Requirements, Achieve a Perfect Linear Light Source. IP20 for Indoor Use Only, IP67 for Outdoor Use Only, Multiple Functions, Used in Multiple Occasions
| Product Information |
| Item | 8MM 10W/M Flexible Led Cob Strip light |
| Product name | Flexible Soft COB Light Strip |
| Power | 10W/M, 50W/Roll |
| Voltage | DC12V/ DC24V |
| light color | Red / Blue/ Green / Yellow/ 2700K/3000K/4000K/6500K |
| Chip Material | InGaN |
| CRI | 90 |
| Luminous efficacy | 110-120LM/W |
Specification
- LEDs Type: 8MM 10W/M Flexible Led Cob Strip
- Input Voltage: DC24V/ DC12V
- Wattage: 10W/Meter
- Total length: 3.3Ft/ M
- FPCB width: 10MM
- View angle: 120°
- LED quantity: 480LEDs
- Lumen: 1100-1300lm
- Color Rendering Index: ＞90
- Waterproof level: IP20 Non-waterproof/ IP67 waterproof
- Color temperature: 2700K/ 3000K/ 4000K/ 6500K/ Red/ Blue/ Green/ Yellow
- Operation temperature: -20℃-+45℃
- Storage temperature: -40℃-+85℃
Product characteristic parameters
| Company abbreviation | Product size (mm) | Input voltage (V) | Half a meter powe (W) | emitting color | CRI | Photosynthetic efficiency level (lm/w) | Color tolerance |
| (xuancai) | 500*08mm | DC24V | 5W | 2700K | ＞90 | 100-105 | ≤3 |
| (xuancai) | 500*08mm | DC24V | 5W | 3000K | ＞90 | 105-110 | ≤3 |
| (xuancai) | 500*08mm | DC24V | 5W | 4000K | ＞90 | 120-125 | ≤3 |
| (xuancai) | 500*08mm | DC24V | 5W | 6500K | ＞90 | 125-130 | ≤3 |
Product appearance dimension drawing
Reliability test standards
| (Apilot project) | (Number of test) | (Test conditions) | (Decision criteria) | (Test Vequipment) |
| Cold and hot shock | 10pcs | -40℃/30min -- 120℃/30min, one Cycle per hour, 100 cycles in total. | No glue crack/dead light | Cold and heat shock chamber |
| The normal temperature aging | 10pcs | Ambient temperature 25±5℃, rated voltage /1000hr, 168H to test the photoelectric parameters once. | 1Droop 10% or less 2.No glue crack/dead light | Normal temperature aging block |
| High temperature and high humidity | 10pcs | Ambient temperature 85±5℃, rated voltage /1000hr, 168H to test the photoelectric parameters once. | 1.Droop 10% or less 2. No glue crack/dead light | High temperature and high humidity aging tank |
Packing method
1. Reel packaging
| LED light barwidth | Reel size | Meters per roll | Number of rolls per carton |
| 4mm | 5.1 inches | 5 | 10 |
| 8mm | 5.1 inches | 5 | 10 |
| 10mm | 5.1 inches | 5 | 10 |
2. Blister box packaging
| LED light barwidth | Blister box size | The packing layer | Number of packing strips per carton |
| 4mm | 510*123*25mm | 10 | 300 |
| 8mm | 510*123*25mm | 10 | 150 |
| 10mm | 510*123*25mm | 10 | 120 |
Application to Anywhere You Want to Use
Wonderful Colored Lighting for Stair, Swimming pool, Bedroom, Ceiling, Kitchen Cabinet, Cupboard, Bar, Billboard , Bedroom , Decoration ... etc.
Trade Show
FAQ
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 2-3years warranty to our products.
Q7: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
